Built-in rooted Android.
8GB internal storage.
With WiFi and Ethernet.
4G is optional.
Certified by CE FCC ROHS.
With an ear on either side， which enable it be integrated into POP displays more easily.
Full view angle.
Present a super-clear picture.
Support 1080P video, powerful video engine, capable of multiple videos decoding.
Built with WIFI for internet connection.
With android based system integrated, support installing 3rd party APK via SD card/USB disk. K-smart is installed by default, to make the screen to be more interactive.
Remotely control media playing,support video,photo playing.
Support playing subtitles, weather.
Remotely Content Management(CMS), support sending contents from office to Tablets.
Kerchan Android interactive advertising monitors are widely used in various public areas where businesses need to display advertising from retail stores, meeting rooms, restaurants, bank, supermarket, airport to hospital and any commercial environment.
| Model | SAD1030KA | Shell color | Standard: black |
| Open Frame or Enclosed | Open Frame | LCD Panel | 10.1inch |
| Resolution | 1280*800 | Display Ratio | 16:10 |
| Brightness | 330cd/m2 | Contrast | 600:1 |
| Colour | 16.7M | Visible Angle | 178/178 |
| Response Time | 5ms | Life Time(hrs) | >20000H |
| Visible Area | 216.96×135.6mm(H×V) | Outline dimension | 259*153.6*25.6mm |
| CPU | A83T, Eight Core, 2GHz | GPU | PowerVR SGX544 |
| Memory | DDR3 2GB | ROM NAND flash | 8GB |
| Decoded Resolution | Support 1080P | RTC Real-time Clock | Support |
| Switch Time Setting | Support | System Update | SD card update |
| OS | Android 6.0 | External Interface | DC IN/MINI USB /USB/Earphone/SD |
| Touch Panel | Camera | ||
| Ethernet Support | Internet/Wifi 802.11b/g/n | Speaker | Size: 20MM*40MM, speakers 8R 2W*2 |
| External Port | Support SD/U flash disk | Input | AC 100-240V |
| Output | DC 12V/2A | Power consumption(Watt) | ≤8W |
| Standby(Watt) | ≤1W | Material | ABS material injection process |
| Installation | 75*75mm VESA Wall Mount | Image Format | JPEG/BMP/GIF/PNG |
| Audio Format | MP3, WMA, WAV, EAAC+, MP2 | Video Format | MPEG1、MPEG2、H.264 MP4、AVI、MOV |
| Control Method | Remote control/Mouse | Default Language | English |
| Menu Language | Support Chinese, English | Storage Temperature | -20℃~60℃ |
| Working Temperature | -20℃~55℃ | Storage Humidity | 10%-75% |
| Working Humidity | 20%-80%RH | Product Weight(N.W. ) | 0.9kg |
| Plug Types | US, EU, AU, UK Optional | Package Size | A single package: 235*60*428mm Bulk packages: 575*410*210mm |
| Packaging | 16pcs/Package Package Weight: 16kg (Reference Only) | Accessories | User Guide, Instruction Book, Warranty, Desiccant |
| Optional | / | Notes | / |
